Red signal colour LED high colour light signal system NKMR. 676636.072 ТU
NKMR | 676636.072-01
Red signal colour LED high colour light signal system NKMR. 676636.072 ТU

Red signal colour LED high colour light signal system NKMR. 676636.072 ТU. 3 operating regimes are available: daytime, night work, flickering.

Make request
Product card
FEATURES
voltage pattern, direct voltage or AC current 11,5-12 V
wattage 15 W
error-free running time, equal to or greater than 50000 h
working time of the system, min 15 years
axial lighting force, min 2100 cd
signal colour red
weight, less than or equal to 2 kg
drawing № NKMR.676636.072-01
DESCRIPTION

Red signal colour LED high colour light signal system NKMR. 676636.072 ТU.

Functionality: colour alarm application for safe railway operation and drilling on the districts equipped with a signal operating system based on relay or microprocessor.

Designated area: factory-made rail track and underground railway.

Red signal colour LED high colour light signal system NKMR.676636.072 ТU is designed to replace the retired multi-lens signal equipped with the electric incandescent lamps (KLM).

The equipping is designed to operate in regions with the moderate and the frigid climate (UHL 1) as per GOST Standard 15150-69.

Advantages of the LED ground light signal system over multi-lens signal:

  • optical source is 25 times more reliable;

  • 2 times longer service life;

  • universal power system is operated from director or alternating current mains;

  • operating and support costs are 10-15 times less;

  • the system is cooperable with any type of ground light signal body or light unit (both with silumin- and metal enclosed);

  • 3 operating regimes: daytime, night work, flickering;

  • operating temperatures range between -60 °C and +55 °C;

  • warranty period – 36 month;

  • working time – 15 years;

  • vibration resistance and anti-vandal functionality.
