| Voltage pattern, AC current | 10,5-12 V |
| Power rating of 1 light-optical complex | 15 W |
| Error-free running time by an average, less than or equal to | 50000 h |
| Working time of a LED complex, min | 15 years |
| Luminous intensity оf optical axis | |
| green | 1250 cd |
| lunar-white | 1800 cd |
| red | 1000 cd |
| yellow | 2000 cd |
| blue | 150 cd |
| Quantity of LED complexes SSS weight | 4,5 kg |
| SSS quantity of LED complexes | 5 |
| SKMTR code | 3185641997 |
| Drawing № | 17843-00-00 |
performance reliability of LED complexes is 25 times higher
long - lasting performance; 2 times longer working time
operating and support costs are 10-15 times less
anti-vandal functionality
ground light signal`s LED light unit – 1 piece. Composing body made of silumin with light-optical complexes and sunshields
metal sole of ground light signal– 1 piece. Mode 2. Overcoat - high-temperature zinc
head and chest set – 1 set
mounting wrench – 1 piece
advice note - 1 piece per a parcel of equipment
outfit installation`s label - 1 piece
silumin enclosed
galvanized suite, cupholders for fastening the light unit and design features
