Lunar white signal colour LED light-optical high colour light signal system NKMR. 676636.030 ТU
NKMR | 676636.030-04

Lunar white signal colour LED light-optical high colour light signal system NKMR. 676636.030 ТU

Lunar white signal colour LED light-optical high colour light signal system NKMR. 676636.030 ТU can be used for alarm application for safe railway operation and drilling. NKMR. 676636.030-04. SKMTR Code 3185620810.

Make request
FEATURES
Voltage pattern, AC current 10,5-12 V
Wattage 15 W
Error-free running time, equal to or greater than 50000 h
Working time of the system, min 15 years
Axial lighting force, min 2500 cd
Outlet port diameter 210 mm
Signal colour lunar white lights
Weight, less than or equal to 6 kg
SKMTR code 3185620810
Drawing № NKMR. 676636.030-04
DESCRIPTION
Lunar white signal colour LED light -optical high colour light signal system NKMR. 676636.030 ТU.

Functionality: colour alarm application for safe railway operation and drilling.

This kind of equipment cannot be used as the changing for the cast-iron housing multi-lens signal system equipped with the electric incandescent lamps. They are set into the modern high colour light signal bodies per cable gland

Contents of delivery:

  • lunar white signal colour LED light-optical ground light signal system

  • outfit installation`s label

  • installation`s instruction


Advantages of the LED ground light signal system over multi-lens signal:

  • optical source is 25 times more reliable;

  • 2 times longer service life;

  • operating and support costs are 10-15 times less;

  • anti-vandal functionality.
